Products and Catalogue Download

Catalog Download

crobat ReaderHere you can download our product catalogs which open in PDF files.
In order to view our catalogs, you need the free Acrobat Reader software from Adobe Incorporated. Please click on Adobe Logo and download the software if needed.
* How to save the PDF files For Windows Internet Explore: Right click on the catalog and select "Save Target As" (A), then save the file.

For Marine Service For Power Generation For Resource Development
For Marine Service
Catalog Download
For Power Generation
Catalog Download
For Resource Development
Catalog Download
* For Chinese catalog, please contact us.

Marine Service

PSL-MD Series
PSL-MD Series PSL-MD Series is slight-pressure-type diaphragm valve, which has been developed to intend to use for low temperature and low pressure and has a dominant market share of the liquefied gas carrier such as LPGC. This series has a large coefficient of discharge and high seat tightness and meets almost all ship classification.

Pressurefrom 1 to 250 kPa Temperaturefrom -196 to 125 deg C
PSL-MP Series
PSL-MP Series PSL-MP Series is piston type pilot operated pressure relief valve, which has been developed to intend to use for low temperature and middle pressure and has a dominant market share of pressurized gas carrier such as LPGC. This series has a large coefficient of discharge and high seat tightness and meets almost all ship classification.
Pressurefrom 0.1 to 2 MPa Temperature from -196 to 125 deg C
SL / SJ Series
SL / SJ Series SL / SJ Series has been developed as a safety valve for steam service especially marine main boilers and auxiliary boilers and conform to various ship classifications. This series is designed to withstand severe specifications of high temperature and high pressure.

Pressureto 20.6 MPa Temperatureto 570 deg C
RE Series
RE Series RE Series is the spring loaded safety valve and mainly used for cargo piping. Basic design is based on API526 and it covers wide range of pressure and temperature.
Pressureto 41.36 MPa Temperaturefrom -267.8 to 538 deg C
SP Series
SP Series SP Series is a safety valve made of bronze which conforms to various ship classifications.
Pressureto -2.157 MPa Temperatureto 220 deg C
This is the catalog for Marine Service
* How to save the PDF files *
For Windows Internet Explore: Right click on the catalog and select "Save Target As" (A), then save the file.
Go to page top

Power Generation

SL / SJ Series
SL / SJ Series SL / SJ Series is a safety valve for steam service of boiler which is getting higher temperature and pressure year after year for advancing power generation efficiency. This series have been approved by the National Board of Boiler and Pressure Vessel Inspectors as meets all of demanding requirements from ASME Boiler and Pressure Vessel Code Section I Power Boiler. In addition, it meets with domestic and foreign regulations such as technical standard for thermal power generation and CE mark.
Pressureto 34.8 MPa Temperatureto 604 deg C
RE-STM Series
RE-STM Series RE-STM Series is mainly used for steam piping. This series have been approved by the National Board as a safety valve for steam piping which meets all of demanding requirements from ASME Section VIII. In addition, it meets with domestic and foreign regulations such as technical standard for thermal power generation and CE mark.
Pressureto 41.36 MPa Temperature from -267.8 to 538 deg C
RVK, RHK Series
RVK, RHK Series RVK, RHK Series is a relief valve intended for heat exchanger, which conforms to HEI regulations. We have a wide variety of size from 8 to 30 inches.


PCV Series
PSH Series PCV Series is the power actuated pressure relief valve for steam. The power of this valve is the air or electromagnet.
Pressureto 30 MPa Temperatureto 604 deg C
RPE Series
RPE Series RPE Series has been approved by ASME Section I as the pilot operated relief valve for feed-water system. This series can be used for both vapor and water.
Pressureto 25 MPa Temperatureto 350 deg C
This is the catalog for Power Generation
* How to save the PDF files *
For Windows Internet Explore: Right click on the catalog and select "Save Target As" (A), then save the file.
Go to page top

Resource Development

RE Series
REシリーズ RE Series is the spring loaded safety valve designed and manufactured in accordance with API526. This series meets all of requirements from ASME Section VIII and have been approved by the National Board. In addition, it meets many kinds domestic and foreign regulations and authorizations such as CE mark or TS mark.
Pressureto 41.36 MPa Temperaturefrom -267.8 to 538 deg C
RE (large bore type)
RE (large bore type) Its inlet size is more than or equal to 10 inches. This series meets all of requirements from ASME Section VIII and have been approved by the National Board.
Pressureto 0.35 MPa Temperaturefrom -196 to 538 deg C
RECLP Series
RECLP Series RECLP Series is the pressure relief valve for pump relief. It has the mechanism to pretend chattering caused by a pulsation.
Pressureto 3 MPa Temperaturefrom 0 to 200 deg C
RPS Series
RPS Series RPS Series is the pilot operated valve designed and manufactured in accordance with API526. This series meets all of requirements from ASME Section VIII and have been approved by the National Board. We can offer both the non-flow pop type and non-flow modulate type.
Pressureto 28 MPa Temperaturefrom 0 to 300 deg C
RTE Series
RTE Series RTE Series has been developed for thermal relief.
Pressureto 9.92 MPa Temperaturefrom -196 to 232 deg C
EVDW Series
EVDW Series EVDW Series is the vacuum relief valve which has been developed for the low temperature liquid storage tank. It is characterized by a large amount capacity and simple design.
Pressurefrom -0.22 to 0.66 kPa Temperatureambient temperature
PSL-MD Series
PSL-MD Series PSL-MD Series is the diaphragm type pilot operated valve which has been developed for the low temperature and pressure liquid storage tank of LNG, LPG, or ethylene. It has large coefficient of discharge and high seat tightness.
Pressurefrom 1to 250 kPa Temperaturefrom -196 to 125 deg C
This is the catalog for Resource Development
* How to save the PDF files *
For Windows Internet Explore: Right click on the catalog and select "Save Target As" (A), then save the file.
